| MPN: | 9RA1224P1K001 |
| Produsent: | Sanyo Denki America Inc. |
| Voltage – Rated: | 24VDC |
| Air Flow: | 158.0 CFM (4.42m³/min) |
| Noise: | 50.0dB(A) |
| Power (Watts): | 11.5 W |
| RPM: | 4700 RPM |
| Bredde: | 38.00mm |
| Fan Type: | Tubeaxial |
| Serie: | San Ace 120 |
| Size / Dimension: | Square – 120mm L x 120mm H |
| Static Pressure: | 0.683 in H2O (170.0 Pa) |
| Bearing Type: | Ball |
| Features: | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) |
| Avslutning: | 4 Wire Leads |
| Ingress Protection: | – |
| Operating Temperature: | -4 ~ 158°F (-20 ~ 70°C) |
| Approval Agency: | cURus, TUV |
| Description: | 120X38MM 24VDC TACH/PWM |
| Detailed Description: | Fan Tubeaxial 24VDC Square – 120mm L x 120mm H Ball 158.0 CFM (4.42m³/min) 4 Wire Leads |
| Current Rating (Amps): | 0.480A |
| Voltage Range: | 21.6 ~ 26.4VDC |
| Material – Frame: | Plastic |
| Material – Blade: | Plastic |
| Lifetime @ Temp.: | Varies Based on Temperature |
