| MPN: | OD1225-48HBIP68 |
| Produsent: | Orion Fans |
| Voltage – Rated: | 48VDC |
| Air Flow: | 120.0 CFM (3.36m³/min) |
| Noise: | 42.0dB(A) |
| Power (Watts): | 4.5 W |
| RPM: | 3100 RPM |
| Bredde: | 25.00mm |
| Fan Type: | Tubeaxial |
| Serie: | OD1225 |
| Size / Dimension: | Square – 120mm L x 120mm H |
| Static Pressure: | 0.240 in H2O (59.8 Pa) |
| Bearing Type: | Ball |
| Features: | Auto Restart |
| Avslutning: | 2 Wire Leads |
| Ingress Protection: | IP68 – Dust Tight, Waterproof |
| Operating Temperature: | -4 ~ 149°F (-20 ~ 65°C) |
| Approval Agency: | CE, cURus, TUV, UR |
| Description: | FAN AXIAL 120X25MM 48VDC WIRE |
| Detailed Description: | Fan Tubeaxial 48VDC Square – 120mm L x 120mm H Ball 120.0 CFM (3.36m³/min) 2 Wire Leads |
| Current Rating (Amps): | 0.090A |
| Voltage Range: | 28 ~ 52VDC |
| Material – Frame: | Polybutylene Terephthalate (PBT) |
| Material – Blade: | Polybutylene Terephthalate (PBT) |
| Lifetime @ Temp.: | 60000 Hrs @ 35°C |
