| MPN: | OD172SAP-24HTB |
| Produsent: | Orion Fans |
| Voltage – Rated: | 24VDC |
| Air Flow: | 235.0 CFM (6.58m³/min) |
| Noise: | 52.0dB |
| Power (Watts): | – |
| RPM: | 3300 RPM |
| Bredde: | 50.80mm |
| Fan Type: | Tubeaxial |
| Serie: | OD172S |
| Size / Dimension: | Rectangular/Rounded – 172mm L x 150mm H |
| Static Pressure: | 0.790 in H2O (196.8 Pa) |
| Bearing Type: | Ball |
| Features: | Auto Restart |
| Avslutning: | 2 Terminals |
| Ingress Protection: | – |
| Operating Temperature: | -4 ~ 167°F (-20 ~ 75°C) |
| Approval Agency: | cURus, TUV |
| Description: | FAN AXIAL 172X50.8MM 24VDC TERM |
| Detailed Description: | Fan Tubeaxial 24VDC Rectangular/Rounded – 172mm L x 150mm H Ball 235.0 CFM (6.58m³/min) 2 Terminals |
| Current Rating (Amps): | 0.970A |
| Voltage Range: | 15 ~ 28VDC |
| Material – Frame: | Aluminum |
| Material – Blade: | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Lifetime @ Temp.: | 40000 Hrs @ 60°C |
